Wen TC1318

EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
304 Handle Button Spring 1
305 Switch Button 1
306 Right Handle Cover, Left 1
307 Rod 1
308 Handle Cover Plate 1
6
Phillips Flat-head Self-
tapping Screw, ST4x16
20
309
Phillips Pan-head Self-
tapping Screw, ST4x20
2
310 Left Handle Cover, Right 1
311 Left Handle Cover, Left 1
312 Power Cord 1
313 Power Cord Connector 1
314 Power Cord Sleeve 1
12 Cable Clamp 2
315
Phillips Pan-head Self-
tapping Screw, ST4x18
4
316 Switch 1
NO. PART NO. DESCRIPTION QTY.
214
Phillips Pan-head Self-
tapping Screw, ST3x12
1
400
TC1318-
400ASM
Wheel & Axle Assembly
401 TC1014-403 Wheel Cover 2
402 TC1014-404 R-clip 2
403 Flat Washer, 10mm 2
404 TC0714-080 Wheel 2
405 Flat Washer, 6mm 1
406 Wheel Bracket Assembly 1
407 Release Ring 1
408 Wheel Adjustment Knob 1
409 Wheel Adjustment Spring 1
410 Wheel Adjustment Shaft 1
411
Phillips Countersunk Self-
tapping Screw, ST4x16
2
412 Wheel Bracket Bushing 2
413 Hex Bolt, M6x35 2
19
NOTE: Not all parts may be available for purchase. Parts and accessories that wear
down over the course of normal use are not covered under the warranty.
