15
EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 VC4710-001 Handle Cap 2
2 VC4710-002 Switch 1
3 VC4710-003 Top Cover 1
4 VC4710-004 ST3.9x16 Screw 7
5 VC4710-005 Motor Cover 1
7 VC4710-007 Upper Motor Cover 1
8 VC4710-008 ST3.9x14 Screw 12
9 VC4710-009 Cord Clip 1
10 VC4710-010 Cord Stress Relief 1
11 VC4710-011 Motor Outlet Seal 1
12 VC4710-012 Cooling Hood Seal 1
13 VC4710-013 Motor 1
14 VC4710-014 Motor Isolation Seal 1
15 VC4710-015 Noise Reduction Foam 1
16 VC4710-016 Intake Pipe 1
17 VC4710-017 Lower Motor Cover 1
18 VC4710-018 ST3.9x20 Screw 6
19 VC4710-019 Float Seal 1
20 VC4710-020 Float 1
21 VC4710-021 HEPA Shelf Sealing
Patch
1
No. Part No. Description Qty.
22 VC4710-022 HEPA Frame 1
25 VC4710-025 Suction Base Cover 1
26 VC4710-026 Suction Base 1
27 VC4710-027 Protection Valve
Assembly
1
28 VC4710-028 Blower Outlet 1
30 VC4710-030 Handle 1
31 VC4710-031 Power Cord 1
32 VC4710-032 Wiring Cap 2
33 VC4710-033 Connection Assembly 1
34 VC4710-034 Vacuum Bucket 1
35 VC4710-035 Wheel Base 4
37 VC4710-037 Castor 4
38 VC4710-038 HEPA Filter 1
39 VC4710-039 Ø 37 Gasket 1
40 VC4710-040 Lock Knob 1
41 VC4710-041 Hose 1
42 VC4710-042 Utility Nozzle 1
43 VC4710-043 Crevice Nozzle 1
44 VC4710-044 Extension Tube 2
45 VC4710-045 Storage Hook 1
To Next Page
