Page #24 background image
Wire Material/Color Starts at: Ends at: Purpose, Remarks
W = stranded
wire
(Subunit, PC Board, Terminal) (Subunit, PC Board, Terminal)
S = shielded
cable
162 S red Spec. eff., E F 1, plug 2, pin 16 (shield
cut off)
Perc. drawbars,term. 9 shield to term. 8 Audio from perc.
drawbars to spec.
effects
163 W pink Spec. eff., E F 1, plug 3, pin 17 Control "wah wah speed", term. S 163 and 164 are
interchangeable
164 W pink Spec. eff., E F 1, plug 3, pin 18 Control "wah wah speed", term. A (front)
165 S gray Fixed stops U /Man, G P 1, plug 2, pin
OUT (shield to pin G N D)
Volume control " U/Man";
term. E (front) (shield cut off)
Audio from U/Man
fixed stops to volume
control
166 S green Fixed stops L/Man, G P 1, plug 2, pin
OUT (shield to pin G N D)
Volume control " L/Man'; term. E (front)
(shield cut off) to volume control
Audio from L/Man
fixed
stops
167 W white Switches "Envelope", U S 1, switch
"Long Sustain", term. a
I Envelope control U /Man,
H K 13, term. "Sust.Long"
Long Sustain
168 W yellow Switches "Envelope"; U S 1, switch
"Medium Sustain"; term. A
i Envelope control U/Man, H
K 13, term. " Sust. Med."
Medium Sustain
169 W brown Switches "Envelope"; U S 1, switch
"Short Sustain", term. a
Envelope control U/Man, H K 13, term.
"Sust.Short"
"Short Sustain"
170 W green Switches "Envelope"; U S 1, switch
"Soft Attack"; term. a
Envelope control U/Man, H K 13, term. "Att.
Soft"
"Soft Attack"
171 W pink Switch "Wersito ne" Solder lug strip (W 1 S) AP 2, connector
"Cabinet"; term. 3 (W 1 T)
Control line for tone
cabinet
172 W yellow Switch "Wersitone" Solder lug strip (W 1 S) A P 2, connector
"Cabinet"; term. 5 (W 1 T)
Control line for tone
cabinet
AM 071 (Part)
24
