(8) superposition at the desired angle (0°, 15°, 30°,
45°) (See Fig. K). For other mitre angles, rotate to your
desired angle (use a protractor scale). Following one of
the above procedures, hold the base plate in position
and firmly tighten the bolts to clamp the base plate at
that angle. Finally, check the angle and ensure the base
plate is firmly clamped. The angle markings on the base
plate are accurate for most general purposes but it is
recommended for accurate work to set the angle with a
protractor and make a test cut on other material.
12. DUST TUBE (See Fig. L)
Mount the dust tube (6) into the opening of the base
plate (7). Make sure that the plastic tip of the vacuum
connection engages into the corresponding opening on
the housing as shown in the figure.
13. FINGER PROTECTION
The finger protection is located in front of the blade
holder. Whilst working, it will help prevent accidental
contact with moving blade.
14. DUST BLOWER AIR HOLE
This is a small aperture located underneath the housing
just behind the blade guide. Ensure this is kept clean to
allow the air flow to continually blow dust away from the
cutting area.
WORKING HINTS FOR YOUR JIG
SAW
If your jig saw becomes too hot, especially when used at
low speed, set the speed to maximum and run no Load
for 2-3 minutes to cool the motor. Avoid prolonged usage
at very low speeds.
GENERAL
Always use a blade suited to the material and material
thickness to be cut. Always ensure the work–piece is
firmly held or clamped to prevent movement. For easier
control, use low speed to start cutting, then increase to
correct speed.
Any movement of the material may affect the quality of
the cut. The blade cuts on the upward stroke and may
chip the uppermost surface or face of the work piece.
Ensure your uppermost surface is a non-visible surface
when your work is finished.
CUTTING LAMINATES
Use a fine tooth blade when cutting most laminates and
thin wood materials. To reduce edge chipping, clamp
pieces of waste wood at both ends on both sides and cut
through the waste wood during cutting.
CIRCLE CUTTING
Do not use the pendulum action when cutting tight
circles or angles
PLUNGE SAWING
Plunge cutting may be used only on soft materials such
as wood, aerated concrete, gypsum plaster boards, etc.
Use only short saw blades.
Place the front edge of the base plate on the workpiece
and switch on. Press the machine firmly against the
workpiece and plunge the saw blade slowly into the
workpiece.
As soon as the complete surface of the base plate rests
on the work piece, continue to saw along the cutting line.
(See Fig M, N)
METAL CUTTING
Use a finer tooth blade for ferrous metals and a coarse
tooth blade for non-ferrous metals. When cutting thin
sheet metals always clamp wood on both sides of the
sheet to reduce vibration or tearing of the sheet metal.
Both wood and sheet metal must be cut. Do not force
the cutting blade when cutting thin metal or sheet steel
as they are harder materials and will take longer to cut.
Excessive blade force may reduce the life of the blade or
damage the motor. To reduce heat during metal cutting,
add a little lubricant along the cutting line.
MAINTENANCE
Remove the plug from the socket before carrying out
any adjustment, servicing or maintenance.
Your power tool requires no additional lubrication or
maintenance. There are no user serviceable parts in
your power tool. Never use water or chemical cleaners
to clean your power tool. Wipe clean with a dry cloth.
Always store your power tool in a dry place. Keep the
motor ventilation slots clean. Keep all working controls
free of dust. Occasionally you may see sparks through
the ventilation slots. This is normal and will not damage
your power tool.
If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
