Wesco WS3764 - Component List; Technical Data; Noise Information

5
EN
COMPONENT LIST
1. Variable Speed Control
2. On/Off Switch
3. Lock-On Button
4. Hand Grip Areas
5. Allen Key
6. Vacuum Adaptor
7. Base Plate
8. Angle Plate
9. Pendulum Action Control
10. Roller Guide
11. Saw Blade
12. Finger Protection
13. Blade Holder
14. Parallel Guide
Not all the accessories illustrated or described are included in standard delivery.
TECHNICAL DATA
Type WS3764 WS3764.1 (37 -designation of machinery, representative of Jig Saw)
WS3764 WS3764.1
Voltage 230-240V~50Hz
Power input 550W
No-load speed 0-3000/min
Stroke length 18mm
Bevel capacity ±45°
Cutting capacity, max.
Wood 65mm
Aluminum 12mm
Steel 6mm
Protection Class
/II
Machine Weight 1.89kg
NOISE INFORMATION
A weighted sound pressure L
PA
: 73,9dB(A)
A weighted sound power L
WA
: 84,9dB(A)
K
pA
&K
wA
3.0dB(A)
Wear ear protection.
