REMOVE THIS EXPLODED DRAWING
AND PART LIST FROM THE MANUAL
Save this EXPLODED DRAWING and PART LIST for future reference.
Note: Specifications are subject to change without notice. For information
about ordering replacement parts, see the back cover of the UserÕs Manual.
PART LISTÑModel No. WETL21200 R1000A
Specifications are subject to change without notice. To order replacement parts, see the back cover of this manual.
Key No. Qty. Description
1 1 Filter
2 1 Motor Pivot Sleeve
3 1 Right Frame Guide
4 1 Left Handrail
5 12 Handrail/Latch Screw
6 1 Key/Clip
7 2 Leg Endcap
8 6 Hood Screw
9 1 Speed Potentiometer
10 1 Speed Control
11* 1 Console Assembly
12 1 Battery Cover
13 20 Electronic Screw
14 4 Belt Guide Screw
15 4 Nylon Washer
16 1 Electronic Bracket
17 1 Motor Pivot Bushing
18 1 Motor Belt
19 1 Motor Tension Bolt/Incline Leg Bolt
20 1 Motor Tension Washer
21 1 Tension Star Washer
22 1 Motor Pivot Nut
23 1 Motor/Pulley/Flywheel/Fan
24 1 Pulley/Flywheel/Fan
25 1 Motor
26 1 Motor Pivot Bolt
27 2 8Ó Cable Tie
28 6 Isolator Screw
29 1 Hood
30 1 Hood Shield
31 6 Console Screw
32 1 Right Handrail
33 4 Base Leg Pad
34 1 Motor Belly Pan
35 1 Controller
36 2 Frame Pivot Bolt
37 2 Star Washer
38 1 Upright/Base
39 2 Extension Leg Screw
40 15 Washer
41 2 Wheel Bolt
42 2 Wheel
43 4 Wheel Nut/Incline Nut
44 2 Extension Leg
45 1 Circuit Breaker
46 2 3/8Ó Washer
47 1 Receptacle
48 1 Motor Tension Nut
49 15 Motor Pan Screw
50 1 Right Foot Rail
51 4 Platform Screw
52 1 Front Roller Adj. Bolt
53 1 Wire Harness
54 1 Left Frame Pivot Spacer
55 2 Grommet
56 1 Walking Belt
Key No. Qty. Description
57 1 Choke
58 2 Belt Guide
59 1 Walking Platform
60 2 Isolator
61 1 Sensor Clip
62 1 Euro Power Cord Set
63 1 Front Roller/Pulley
64 1 Ground Nut
65 1 Reed Switch
66 1 Frame Guide Spacer
67 1 Latch
68 9 Wire Tie
69 5 Wire Tie Clamp
70 1 Magnet
71 1 Console Base
72 1 Left Foot Rail
73 2 Rear Platform Screw
74 1 Frame
75 1 Rear Roller
76 2 Ground Screw
77 1 Ground Wire
78 2 Rear Roller Adj. Bolt
79 1 Rear Endcap
80 4 Plastic Fastener
81 1 Allen Wrench
82 1 Latch Decal
83 2 Incline Leg Bolt
84 1 Belly Pan
85 1 Right Frame Pivot Spacer
86 2 Incline Leg Plate
87 2 Incline Wheel
88 4 Incline Leg Nut
89 2 Incline Motor Bolt
90 1 Incline Motor
91 2 Cage Nut
92 2 Hand Rail Bolt
93 2 Hand Rail Washer
94 1 Catch
95 2 Base Leg Assembly
96 2 Incline Motor Bracket
97 2 Incline Motor Nut
98 2 Belly Pan Screw
99 1 Incline Leg
100 2 5/16Ó x 3 1/2Ó Bolt
101 2 5/16Ó Flat Washer
102 2 5/16Ó Nylon Locknut
# 1 4Ó Green/Yellow Wire
# 1 4Ó White Wire, 2 Female
# 2 4Ó Black Wire, 2 Female
# 2 8Ó Green/Yellow Wire
# 1 8Ó White Wire, Pig Tail
# 1 10Ó White Wire, 2 Female
# 1 UserÕs Manual
* Includes all parts shown in the box
# Indicates a non-illustrated part
