PART LIST—Model No. WCTL19108.0 R0608A
K
ey No. Qty. Description
11Console
24Handrail/Base Endcap
3
1 Key/Clip
41Console Back
56Ground Screw
61Right Handrail
71Left Handrail
82Rear Foot
91Motor Tension Bolt
10 2 Frame Bolt
11 2 Handrail Washer
12 4 Handrail Bolt
13 2 Frame Spacer
14 2 Wheel Bolt
15 2 Wheel
16 1 Releasable Tie
17 4 Nut
18 1 Belly Pan Plug
19 6 Base Pad
20 4 Belly Pan Screw
21 1 English Latch Warning Decal
22 1 Wire Harness
23 1 Hood
24 7 Hood Screw
25 1 Belly Pan
26 4 Belt Guide Screw
27 2 Belt Guide
28 2 Roller Spacer
29 1 Allen Wrench
30 1 Reset/Off Circuit Breaker
31 4 Formed Washer
32 1 Controller Bracket
33 2 Star Washer
34 2 Incline Leg Washer
35 1 Controller
36 1 Motor Bolt
37 1 Foot Pad, Left
38 1 Motor Tension Nut
39 1 Motor Star Washer
40 3 Wheel Nut
41 1 Storage Latch
K
ey No. Qty. Description
42 6 Base Pad Screw
43 1 Motor Assembly
4
4 1 Power Cord
45 1 French Large Warning Decal
46 1 Reed Switch
47 1 Wire Tie Clamp
48 1 Reed Switch Clip
49 1 Magnet
50 1 Belt
51 2 Roller Adj. Bolt
52 6 Platform Screw
53 1 Front Roller/Pulley
54 1 Foot Pad, Right
55 1 Frame
56 1 Walking Belt
57 1 Walking Platform
58 4 Console Back Screw
59 2 Endcap Plate
60 1 Ground Wire
61 8 8" Cable Tie
62 1 Power Cord Grommet
63 2 Incline Leg
64 2 Incline Pin
65 1 Voltage Warning Decal
66 2 Roller Adj. Washer
67 2 Frame Endcap
68 2 U-nut
69 1 Latch Pin
70 4 Console Screw
71 1 Base
72 1 Rear Roller
73 3 Latch Screw
74 1 Upright Grommet
75 4 Cable Tie
76 4 #8 x 1/2" Screw
*14" White Wire, Male/Female
*14" Black Wire, 2F
*14" Blue Wire, Female/Flag
*1Userʼs Manual
*These parts are not illustrated.
Specifications are subject to change without notice.
