PART LIST—Model No. WETL13706.0 R0706A
Key
No. Qty. Description
Key
No. Qty. Description
Key
No. Qty. Description
1 2 Frame Pivot Bolt
2 4 Handrail Bolt
3
1 Tie Holder Screw
4 4 Console Back Screw
5 2 Crossbar Screw
6 1 Warning Decal
7 6 Console Screw/
Latch Screw
8 1 Silver Ground Screw
9 2 Handrail Star Washer
10 1 Power Adapter
11 2 Frame Spacer
12 2 Crossbar Star Washer
13 2 Incline Wheel Bolt
14 6 Handrail Washer/
Frame Washer
15 1 Key/Clip
16 6 Nut
17 1 6 mm Hex Key
18 1 4 mm Hex Key
19 2 Roller Bracket Screw
20 5 Hood Screw
21 13 Screw
22 1 Front Roller Adj. Bolt
23 1 Ground Screw
24 2 Outlet Plate Bolt
25 10 Foot Rail Screw
26 6 Base Pad Screw
27 2 Walking Platform
Bolt, Rear
28 4 Belt Guide Screw
29 2 Rear Roller Adj. Bolt
30 2 Motor Bolt
31 1 Motor Pivot Bolt
32 2 Incline Leg Bolt
33
2 Walking Platform
Bolt, Front
34 2 Motor Tension Bolt
35 2 Wheel Bolt
36
2
Rear Roller
Star Washer
37 1 Front Roller
Star Washer
38 2 Motor Star Washer
39 2 Outlet Plate Washer
40 1 Ground Star Washer
41 20 Tek Screw
42 4 Electronics Star
W
asher
43 4 Incline Wheel
44 2 Motor Tension Nut
45 2 Frame Pivot Nut
46 6 Incline Leg Nut/
Platform Nut
47 5 Hood Clip
48 1 Latch Assembly
49 3 Small Nut
50 2 Isolator Fastener
51 1 Frame
52 1 Base
53 1 Left Handrail
54 1 Right Handrail
55 1 Rear Roller
56 1 Motor Belt
57 1 Electronics Bracket
58 1 Dust Guard
59 1 Motor Bracket
60 1 Left Rear
Roller Bracket
61 1 Right Rear
Roller Bracket
62 1 Magnet
63 6 Base Pad
64 1 Latch Catch
65 1 Hood
66 1 Belly Pan
67 1 Left Foot Rail
68 1 Right Foot Rail
69 2 Incline Leg
70 2 Wheel
71 1 Front Roller/Pulley
72
1 Motor Isolator
73 2 Motor Bushing
74 2 Frame Endcap
75 4 Base Endcap/
Upright Endcap
76 1 Walking Belt
77 2 Platform
Cushion, Front
78 2 Platform
Cushion, Center
79 1 Drive Motor
80 4 Wire Tie
81 4 8” Tie
8
2 2 Tie Holder
83 1 Reed Switch Clip
84 1 Belly Pan Grommet
85 2 Grommet
86 1 Walking Platform
87 1 Controller
88 1 Transformer
89 1 Filter
90 1 Power Cord
91 1 Console Assembly
92 1 Console Crossbar
93 1 Console Back
94 2 Belt Guide
95 1 Ground Wire
96 1 Ground Wire
97 1 Reed Switch
98 1 Wire Harness
99 1 Outlet Plate Assembly
100 2 Lift Motor Bolt
101 1 Stop Bracket
102 2 Lift Motor Nut
103 1 Belly Pan
104 1 Incline Wire
105 4 Transformer Screw/
Filter Screw
106 1 Shield
107 1 Incline Motor
# 1 6” Red Wire, M/F
# 1 4” Black Wire, M/F
# 1 4” Blue Wire, M/F
# 1 8” Blue Wire, 2F
# 1 10” Blue Wire, 2F
# 1 6” White Wire, 2F
#
1 10” White Wire, 2F
# 1 User’s Manual
#These parts are not illustrated.
Specifications are subject to
change without notice.
