11
12. Make sure that all parts are properly tightened before you use the treadmill. To protect the floor or car-
pet, place a mat under the treadmill. To avoid damage to the console, keep the treadmill out of direct sunlight.
11. Remove the paper backing from the Adhesive
Clip (19). Press the Adhesive Clip onto the left
side of the Frame (10) in the indicated location.
Then, press the Hex Key (21) into the Adhesive
Clip.
Make sure that the walking belt is properly
tightened (see page 16).
Then, lubricate the walking platform (see
page 15).
19
21
10
11
10. Hold the Console (18) near the Center Handrail
(16). Connect the wire on the Console (B) to the
Upper Handrail Wire (17).
Attach the Console (18) to the bracket on the
Center Handrail (16) with four M4 x 12mm
Screws (4); start all four Screws, and then
tighten them. Do not overtighten the Screws.
Make sure that the wires are not pinched.
10
18
B
16
4
4
17
To Next Page
