WEST 1600 - HYDRAULIC SYSTEMS; 1300 Dual Spreader Hydraulics; 1600 Dual Spreader Hydraulics; 2000 Dual Spreader Hydraulics


HYDRAULICS
REF
PART NO DESCRIPTION QTY REF PART NO DESCRIPTION QTY
1300 Dual Spreader 1600 Dual Spreader
1 990201 Male Q/R coupling 2 1 990201 Male Q/R Coupling 2
2 990202 Female Q/R coupling brake 1 2 990202 Female Q/R Coupling 1
3 990206 ½Dowty Washer 3 3 990206 ½Dowty Washer 3
4 990213 ¼" MMM 'T' Junction 1 4 990213 ¼" MMM 'T' Junction 1
6 200503 Brake cylinder 2 6 200503 Brake cylinder 2
7 110502 Front Door Hose (5.76m) 1 7 110502 Front Door Hose (5.76m) 1
8 110501 Rear Door Hose (6.63m) 1 8 110501 Rear Door Hose (6.63m) 1
9 110507 Brake hose to tractor (5.6m) 1 9 110507 Brake Hose to tractor (5.6m) 1
10 110504 RH Brake Hose (1.07m) 1 10 160506 RH Brake Hose (1.07m) 1
11 110503 LH Brake Hose (0.83m) 1 11 160505 L H Brake Hose (0.83m) 1
2000 Dual Spreader 3000 Dual Spreader
1 990201 Male Q/R Coupling 2 1 990201 Male Q/R Coupling 2
2 990202 Female Q/R Coupling 1 2 990202 Female Q/R Coupling 1
3 990206 ½ Dowty Washer 3 3 990206 ½ Dowty Washer 3
4 990213 ¼ MMM 'T' Junction 1 4 990213 ¼ MMM 'T' Junction 1
6 990623 Brake Cylinder 2 6 990623 Brake Cylinder 2
7 200543 Door Hose (6.0m) 1 7 200543 Door Hose (6.0m) 1
8 As 7 Door Hose (6.0m) 1 8 As 7 Door Hose (6.0m) 1
9 200544 Brake Hose to tractor (6.0m) 1 9 570544 Brake Hose to tractor (6.0m) 1
10 200545 RH Brake Hose (0.83m) 1 10 200545 RH Brake Hose (0.83m) 1
11 200546 LH Brake Hose (1.07m) 1 11 200546 LH Brake Hose (1.07m) 1
PLEASE STATE THE CORRECT MACHINE SERIAL NUMBER AND PART NUMBER WHEN ORDERING PARTS

