WEST 1600 - Tyre Pressures; Bolt Torques; Wheels, Axles and Drawbar Torques

5
Tyre Pressures
Model
Tyre Size Bars P.S.I
1300 18.4 x 26 x 12 ply 2.6 38
1600 23.1 x 26 x 14 ply 2.3 33
2000 23.1 x 26 x 16 ply 2.6 38
3000 650/65-30.5 x 16 ply 2.2 32
Bolt Torques
Bolt Torque Data Black Bolts Plated nuts
N/m. Kg/m Lbs./ft
M8 Grade 12.9 46.4 4.75 35
M8 Grade 8.8 28 2.9 21
M10 Grade 8.8 56 5.74 42
M12 Grade 8.8 98 10.0 72
M16 Grade 8.8 244 25.0 180
M20 Grade 8.8 476 48.0 352
M22 (wheel) Grade 370 38 273
Wheels, Axles and Drawbar Torques
Wheel Sprung Axle Drawbar
1300 360 N/m - -
1600 360 N/m - -
2000 360 N/m - -
3000 360 N/m - -
