1300 & 1600 STUB AXLE
REF
PART NO DESCRIPTION QTY REF PART NO DESCRIPTION QTY
1
10053 Hub cap 2
2
14367 Split Pin 2
3
5802061 Castle Nut 2
4
7329307 Washer 2
5
1328981 Hub (8x22mm Stud) 2
6
505026 Outer Bearing 32211 2
7
3260193 Wheel Stud M18 16
8
10115 Wheel Nut M18 16
9
908408S Stub Shaft 2
10
505027 Inner Bearing 32017 2
11
6002064 Rear Washer 2
12
4008054 Spring 4
13
408100S Back Plate 2
14
Cam Shaft 2
15
Brake lever 2
17
4008053 Brake shoe & Linning 4
18
Grease nipple 2
19
WB1215 Sealing washer 2
20
Circlip 2
21
408TSM80 Drum (8 x 18Ø studs) 2
23
CBAG2032 Bearing Cam shaft 2
24
Circlip 2
PLEASE STATE THE CORRECT MACHINE SERIAL NUMBER AND PART NUMBER WHEN ORDERING PARTS
34
