Westbo of Sweden
Westbo Classic
Mounting instructions
Assembling
1. First unpack the stove and make sure everything
is delivered and that nothing is missing or damaged.
In case of damage please report to the carrier imme-
diately.
2. Remove the bottom part of the stove (main body)
from the pallet and put it in place. Then remove the
transportation lock. pic 1.
3. Place the upper smoke deector in steel on top of
the mainbody. pic 2.
4. Remove the upper part of the stove from the
pallet. pic 3
Save the bolts and braces for later.
5. Unscrew the smoke pipe from the pallet. pic 4
Place it on the mainbody against the sealing
rope. If you ordered the stove with adjustable ring
this is the step to assemble this. pic 5
