Western Airconditioning Epsilon Echos+ 9 - Page 35

Epsilon Echos +
35
Dimensional diagram Epsilon Echos+
20 1PS
C413210 - A
"A"
CLEARENCES
G1
G2
G4
G3
FOOTPRINT
566
506
1850
1105
1296 321
192
O 9HOLES
1100
2046020
175
840
85
300
Denomination - Dimensional Drawing Drawing Rev.
DraftsmanDate
Scale
Checked by
di
Sheet
N.
of
Replace draw. Replaced by draw.
Weight [kg]
DIM.DRAWING EPSILON ECHOS PLUS 20 1PS
C413210/
A
BARBETTA
1
/
/
1
TURRI16/11/121:25
/
Code
MTE 56 rev. 04 date: 07/04/11
Reserved property, reproduction prohibited accordin to existent
laws.Copyright.
VIEW FROM "A"
Pm
Es
Ep
Rp
Lh
Rp
Uout
Uin
Cdh *
232,5
300
600
900
Uin Uout
G 1" 1/4 F G 1" M
25115730115115
500
NOTE
OPTIONAL (ø22 mm)
Cdh *
Rp
41,5
503 21,5 861,5 241,5
MODEL WEIGHT(Kg) OPERATING WEIGHT(Kg) G1(Kg) G2(Kg) G3(Kg) G4(Kg)
EPSILON ECHOS PLUS 20 CH_1PS 293 426 121 68 86 151
EPSILON ECHOS PLUS 20 HP_1PS 310 443 125 70 87 159
