Western 1200 - PARTS BREAKDOWN

8
PARTS BREAKDOWN
Return to Table of Contents
PARTS BREAKDOWN
20
21
22
23
1200-200-130
1200-200-240
1200-200-230
501-0PC-321
1200-200-210
1200-200-211
00336206ZNR
1200-200-211
1200-200-200
1200-200-190
00336208ZZC
1200-200-080
1200-200-090
1200-150-130
1200-150-110
1020-00-0006
1200-200-060
1200-200-120
1200-200-110
1200-150-100
1200-200-020
1200-150-060
1200-150-020
1200-200-050
1200-200-100
5010LC100535
5010LC100543
5010LC100519
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
½ x PLUG
INSPECTION GASKET
INSPECTION PLATE
⁄ STUD
INPUT SHAFT
INPUT RING
BEARING
INPUT RING
INPUT SEAL
HOUSING
BEARING
SEAL OUTPUT
OUTPUT SHAFT
SHAFT COUPLER
SHAFT PIN
NUT LOCK ⁄
OUTPUT RING
GEAR INTERNAL
KEY WAY
SHIFTER HANDLE
SHIFT SHAFT
CLUTCH FORK
PIN GROVED
MAIN GEAR
GEAR INTERMEDIATE
DRIVE MEMBER ASSY.
PRESSURE PLATE ASSY.
RELEASE BEARING
Part Number
Ref
Description
12
7
19
17
24
11
3
4
567810
18
25
12 13
14
15 16
7
7
9
26 27 28
