Westinghouse Halley - Mounting Bracket Installation; Canopy Screw Adjustment; Separating Mounting Bracket

7
ETL-ES-Halley Smart B-WH21
1
1
2
2
3
4
Remove the screws from the two mating holes (1) on the canopy. Loosen
(do not remove) the screws in the mating slots (2) on the canopy.
Rotate the mounting bracket and remove from the canopy.
Quite los tornillos de los dos agujeros coincidentes (1) del dosel. Afloje (no
quite) los tornillos de las ranuras coincidentes (2)del dosel.
Gire el soporte de montaje y sepárelo del dosel.
MOUNTING BRACKET INSTALLATION
INSTALACIÓN CON SOPORTE DE MONTAJE
