Technical data
Dimensions Width cm 60
Height cm 85
Depth cm 63,5
Electrical connection - Voltage -
Overall power - Fuse
Information on the electrical connection is given on the rating plate
on the inner edge of the dishwasher door.
Water supply pressure Minimum 50 kPa (7 psi)
Maximum 800 kPa (116 psi)
Capacity Place settings 12
Installation
Fitting under a counter
Warning! Make sure that mains plug is
disconnected from the mains socket
during installation.
Put the appliance adjacent to a water tap and
a water drain.
The plinth of a freestanding appliance is not
adjustable.
Do not remove the appliance's worktop if you
want to use it as a freestanding unit.
It is not necessary to remove the worktop
when installing under a standard kitchen
bench top.
Only remove the appliance worktop to install
it under a close fitting sink unit or kitchen
worktop (820mm).
Make sure that the dimensions of the recess
agree with the given dimensions.
Follow steps listed below to remove the
appliance worktop
1. Remove the rear screws (1).
2. Pull the worktop behind the appliance (2).
3. Lift the worktop and move it from the front
slots (3).
4. Level of the appliance using the adjusta-
ble feet.
5. Install the appliance under the kitchen
worktop. Ensure that water hoses are not
kinked or squashed.
The appliance must be easily accessible to
the technician if a repair is necessary.
Adjusting the level of the appliance
Make sure that the appliance is level to close
and seal the door correctly. If the level of the
appliance is correct, the door does not catch
on the sides of the cabinet. If the door does
not close correctly, loosen or tighten the ad-
justable feet until the appliance is level.
westinghouse 15
