INSTALLATION
Replacing the oven door
(to be done by qualified personnel only)
1. Hold door with both hands.
2. Locate both hinges into the frame slots at the
same time.
installation
Procedure to assemble the door
(to be done by
personnel only)
Procedure to assemble the door (to be done by qualied personnel only).
3. Open door fully and rotate
the stirrups away from you,
back to their original position.
1. Hold door with both
hands and locate both
hinges into the frame slots
at the same time.
Frame slot
Hinge
Notch
4. Close the door fully.
2. Ensure that the location notch drops into the
frame slot.
Care should be taken not to damage other
parts of the cooker.
1. Hold door with both hands.
2. L ocate both hinges into the frame slots at the
same time.
3. E nsure that the location notch drops into frame
slot. Care should be taken not to damage other
parts of the cooker.
4. O pen door fully and rotate stirrups away from
you back to their original position.
5. C lose the door fully.
Chef 540 Upright Cooker INSTALLATION 19
Notch
3. Ensure that the location notch drops into frame
slot. Care should be taken not to damage other
parts of the cooker.
Notch
Hinge
Frame slot
4. Open door fully and rotate stirrups away from
you back to their original position.
INSTALLATION
5. Close the door fully.
6. Carefully remove any protective plastic film to prevent
damage to the appliance.
To Next Page
