Westward Operating Instructions and Parts Manual
Hydraulic Quick Lift Service Jacks
Manufactured for Grainger International, Inc.
100 Grainger Pkwy., Lake Forest IL 60045 U.S.A.
For Repair Parts, call 1-800-323-0620
24 hours a day - 365 days a year
Please provide following information:
-Model number
-Serial number (if any)
-Part description and number as shown in parts list
Item Description 13X032A Part No. 13X037A Part No. Qty
1
2
3
4
5
Hydraulic Power Unit
Front Wheel Assembly
Rear Caster Assembly
Saddle
Vent Screw Assembly
G730-04000-000
G730-90009-K01
G520-90026-K02
G730-00004-000
G62S-03300-200
G25L-03000-000
G730-90009-K01
G520-90026-K02
G700-00004-000
G62S-03300-200
1
2
2
1
1
6
7
8
9
10a
10b
U-joint Assembly
Handle
Handle Grip
Handle Retaining Bolt
Spring, Handle Fork (right)
Spring, Handle Fork (left)
G730-90009-K04
G730-90009-K02
G933-00001-000
5102-08018-000
G931-00009-000
G610-00008-000
G730-90009-K04
G730-90009-K02
G933-00001-000
5102-08018-000
G931-00009-000
G610-00008-000
1
1
1
1
1
1
11
12
13
14
15
Spring, Lift Arm
Spring, Pump
Bolt
Lock Washer
Bolt
G931-00003-000
G610-03005-000
G610-00009-000
5303-00020-000
G62S-00008-000
G931-00003-000
G610-03005-000
G610-00009-000
5303-00020-000
G62S-00008-000
2
1
1
2
4
16
17
18
19
*
Lock Washer
Cover
Pump Piston Assembly
Handle Fork
Repair Kit
5303-00012-000
G730-00005-000
G730-04200-000
G62S-05000-000
G6122S-120
5303-00012-000
G700-00002-000
G730-04200-000
G62S-05000-000
G6122S-120
4
1
1
1
-
A
A
1
F
6
K
11
P
U
B
G
7
L
L
12
Q
17
C
3
H
H
8
M
M
N
N
R
18
D
4
9
N
S
V
19
E
5
J
J
10b
10a
T
W
16
2
13
14
15
Figure 2 - Repair Parts List
