The use of fuel that does not meet the following criteria will
void the product warranty.
• Use fuel rated to a minimum of 91 RON.
• Contains a maximum level of 10% ethanol (E10).
• Contains a maximum level of 10% MTBE.
• It is acceptable to use fuel containing up to 5% methanol
by volume, as long as it also contains cosolvents and
corrosion inhibitors to protect the fuel system.
ENGLISH
GARDEN LAWN TRACTOR
Operator Manual
F Series / T Series
Models T50, T60, T80, F60-4WD & F250-4WD
October 2014 issue
Part No. 366015600 D

Table of Contents

Questions and Answers

  • D
    Destiny BaldwinAug 20, 2025
    How to fix engine fails to start on Westwood T Series?
    • W
      williamthompsonAug 20, 2025
      To resolve engine start failure in your Westwood Lawn Mower, ensure you're seated on the tractor, the parking brake is disengaged, and the PTO switch isn't engaged. Set the throttle between 25-50% when starting; if unsuccessful, try 75-100%. If it still fails, apply the choke during ignition. Also, verify all fuses are intact and replace any that are blown. Finally, check that the front exhaust outlet is clear. Remember to turn the ignition off for at least two seconds before attempting to restart.
  • K
    karenswansonAug 22, 2025
    What to do if the engine misfires, loses power or stalls in use on Westwood Lawn Mower?
    • R
      Rebecca CalhounAug 22, 2025
      If your Westwood Lawn Mower engine misfires, loses power, or stalls during use, first check that you haven't run out of fuel. Then, verify that the air filter and engine cooling air intakes are not blocked. Also, ensure that fuse 4 (brown, 7.5amp) has not blown or been dislodged.
  • A
    Amber DorseyAug 25, 2025
    Why does the cutter fail to start or cut out when switched on my Westwood Lawn Mower?
    • M
      Mary OconnorAug 25, 2025
      If your Westwood Lawn Mower cutter fails to start or cuts out when switched on, ensure you are seated on the tractor, as the safety switch will disable the cutter deck if you're not. Verify that the correct function is selected on the dashboard. Also, check if the cutter switch or the safety switch on the seat is faulty and ensure the battery is well-charged, as a low battery can prevent the clutch engage switch from operating.
  • K
    Kelsey Lopez DDSAug 26, 2025
    How to fix uneven cutting on Westwood T Series?
    • A
      andrew92Aug 27, 2025
      To address uneven cutting with your Westwood Lawn Mower, ensure all tires are inflated to the correct pressures. Check that the front axle is pivoting freely and the deck brackets are moving without locking up. Verify the deck is level from side to side and back to front. Finally, inspect the cutter blades for wear or damage.
  • L
    Laura SmithAug 28, 2025
    What to do if the engine fails to restart during field use on Westwood T Series?
    • C
      chavezgregoryAug 28, 2025
      If your Westwood Lawn Mower's engine fails to restart during field use, recheck all the points listed for initial starting issues. Remove the ignition key, engage the parking brake, and wait for all moving parts to stop. Raise the deck for a visual inspection, and if you find an obstruction, manually move the tractor away from the area. Remove the deck if necessary for safe removal. Also, check for obstructions under the chassis.
  • J
    Jeffery MillerAug 29, 2025
    Why does the cutter lose power and the belt slip and overheat on my Westwood T Series Lawn Mower?
    • C
      Charles WatkinsAug 29, 2025
      If your Westwood Lawn Mower's cutter seems to lose power and the belt slips and overheats, ensure the cutter belt tension is correct. Check that the cutter deck isn't clogged with wet cuttings and that the cutter drive belt isn't worn. Also, make sure the cutter deck is set parallel to the surface it is cutting.
  • H
    Holly MartinezAug 31, 2025
    Why does my Westwood T Series Lawn Mower have an uneven cut (cuts shorter one side than the other)?
    • K
      Kelly LeachAug 31, 2025
      If your Westwood Lawn Mower displays an uneven cut that's shorter on one side, verify that all tires are inflated to the correct pressures and that the front axle is pivoting freely. Also, confirm that the deck brackets are moving freely without hitching and that the side deck level adjustment is correct.
  • B
    Brianna MarshallSep 2, 2025
    What to do if the engine turns over and does not start on Westwood T Series?
    • N
      Nicholas HallSep 2, 2025
      If your Westwood Lawn Mower engine turns over but doesn't start, check that the fuel tank is full and the outlet in the fuel tank isn't blocked. Also, ensure the fuel filter isn't blocked and that fuse 2 (brown, 7.5 amp) hasn't blown or been dislodged.
  • J
    james92Sep 4, 2025
    Why do the tyres spin or lose grip on my Westwood T Series Lawn Mower?
    • G
      ghansenSep 4, 2025
      If the tyres on your Westwood Lawn Mower spin or lose grip, ensure that all tyres are inflated to their correct pressures. Also, consider whether you are going too fast for the conditions.
  • M
    Michelle OconnellSep 6, 2025
    What to do if the cutter deck seems to require levelling on Westwood T Series?
    • J
      James OlsonSep 6, 2025
      If your Westwood Lawn Mower's cutter deck seems to require leveling, check that the tires are correctly inflated according to the specifications. Ensure the cutter deck hanger brackets are moving freely and not hitching. Also, verify that the front axle is pivoting freely and inspect for any impact damage that may have bent or distorted the deck or suspension brackets.

Summary

Safety Rules

Safety Decals and Symbols

Explains signal words, alert symbols, and decal meanings for safe operation.

Operator and Child Safety

Covers training, age, children, and personal protection for safe use.

Operational and Fuel Safety

Details on operating conditions, slopes, fuel, towing, and accessories.

Maintenance and Transport Safety

Safety for batteries, service, transporting, and storage.

Tractor Control Layout

Main Control Locations

Dashboard Display Functions

Key Operational Controls

Details on choke, ignition switch, RMO system, and throttle controls.

Indicator Lights and Gauges

Operating the Tractor

Driving and Parking

Instructions on moving, stopping, parking, and transmission bypass.

Cutting Grass Operations

How to engage and operate the cutting deck and RMO system.

Grass Collection System

Using the PGC, engaging PTO, and net emptying procedures.

Sweeper Height and Grass Collection

Cutter Deck Installation

Tension Rod Installation

Instructions for installing the deck tension rod assembly for belt tension.

Adjusting Deck Tension Rod

Steps to adjust the tension rod for proper belt tension.

Deck Levelling Procedures

Powered Grass Collector (PGC)

PGC Fitting and Lift Lever

PGC Connection to Tractor

PGC Drive Belt and Lock Adjustment

Routine Maintenance

Engine and Battery Care

Drive Belt Maintenance

Troubleshooting Guides

Engine Starting and Running Issues

Diagnosing engine start, restart, misfires, power loss, and stalling.

Electrical and Accessory Problems

Cutting and Grass Collection Problems

Tyre and Wheel Problems

Westwood T Series Specifications

General IconGeneral
BrandWestwood
ModelT Series
CategoryLawn Mower
LanguageEnglish
