7
Important:
When charging the battery for the first
time or after a longer period of time
calculate approx. 24 h to reach the max.
capacity.
Charging Process:
Connect battery charger to an outlet 230
V, 50- 60 HZ. Push battery firmly into the
battery charger. A signal lamp lights up
during the charging process. When the
max. charging capacity is reached, an
internal electronic guard circuit prevents
that the battery is being overcharged.
As long as the battery is still hot, e. g.
immediately after intensive use, the
charging process doesn’t start.
Inspect the contacts for dirt, if the charging
control lamp doesn’t light up and make
sure the battery has been pushed
completely into the charger.
Let the battery tool cool down sufficiently
after each use before charging it anew.
When the charging process has been
completed the lamp goes off.
The signal lamp may light up, when a
charged battery is being inserted. This
represents however no defect.
Approx. charging time: 15 min.
Technical Data: EHC 10 Tool Technical Data: Battery Charger
Crimp cycles/charge min. 50 Suitable for battery DC 12 V
Max. compacting pressure
100 kN
(21,000 lbs.)
Primary voltage 230V /50-60 Hz
Dimensions
Secondary voltage 12 V DC
Length approx. 310 mm Input 80 VA
Height approx. 240 mm Average charging time 15 min
Weight approx. 4,5 kg
Weight
0,71 kg
