OPERATING MANUAL AND USER GUIDE

CONNECTION DIAGRAM

connecting multiple v series speakers together in a mono-main and stage monitor conguration using a single,

dual channel amplier.

MONO MAIN SYSTEM WITH TWO MONITORS

NOTE: This conguration represents a 4 ohm load to each output channel of the amplier.

V15B and V18B System Set-ups

V15B and V18B Stereo Sub with Passive Satellites

This is example shows a system with a single power ampliyer connecting the subs and satellites in stereo.

The mixer’s left and right outputs are connected to the inputs of the power amplier using shielded cable. The

outputs of the amplier are connected to the V15B or V18B INPUT using un-shielded speaker cable. Next, run

an un-shielded speaker cable from the V15B’s or V18B’s EXTENSION OUTPUT to the two satellite speakers.

For details on wiring your speaker cables.

IMPORTANT NOTE:

To avoid any possible damage to your amp and speakers, be sure to check the

manufacturer’s owners manual to conrm your power ampliyer is capable of operating at 2 ohms.
