USER INSTRUCTIONS: WH-S8 & WH-S10 SUBWOOFER
3
Control Panel of the WH-S10 Subwoofer
①
Power Indicator
②
Mains Power Switch
③
Mains Power Fuse
④
IEC Mains Input Socket
⑤
Volume Control
⑥
Crossover Frequency Control
⑦
Phase Switch
⑧
Auto Power Switch
⑨
LFE Input
⑩
Line Level Outputs
Line Level Inputs
11
⑤
⑥
⑦
⑧
⑨
⑩
①
②
③
④
11
CONNECTING THE SUBWOOFER TO THE SYSTEM
