FIGURE 1.
SURFACE WALL MOUNTING
For surface mounting, be sure to use hardware suitable for the mounting surface.
FIGURE 2.
Power and Grounding
The 120 VAC line cord has a three-prong plug which should be plugged into a three wire grounded electric outlet. It is
very important to maintain the amplifier ground for safe and trouble-free operation. If there is no grounded electric outlet,
connect a wire from the GND terminal of the unit to a water or steam pipe.
P81932 H
SHEET 2 OF 7
TECHNICAL SPECIFICATIONS
