FIGURE 7.
OPERATION
FIGURE 8.
(Front panel controls, switches and indicators.)
NOTE:
ALL CONTROLS ROTATE CLOCKWISE TO INCREASE AND
COUNTERCLOCKWISE TO DECREASE.
POWER SWITCH (ILLUMINATED): The amber light inside the switch will light when the AC cord is plugged into a 120
VAC source and the power switch is pressed to the ON position.
MASTER VOLUME CONTROL: Sets the total output level of the amplifier without disturbing the individual level settings
of the microphone, telephone and music inputs.
P81932 H
SHEET 6 OF 7
TEL/MIC 1 SELECTOR SWITCH: Switch to TEL position when using telephone input paging, or switch to MIC 1 position
when using MIC 1 input.
AUX 1/AUX 2 SELECTOR SWITCH: Switch to either AUX 1 or AUX 2 position, depending upon which of 2 program
source inputs are utilized.
TEL/MIC 1 CONTROL: Adjusts the volume of either the telephone paging or MIC 1 paging input.
