3-7
b)Pull the oven burner forward and slide
it off the orifice at the back.
c) Pull the ignitor wiring out of the liner
cutout until you can access the connec-
tor and disconnect it from the harness.
6. To remove the burner ignitor, remove
the two hex-head screws.
Orifice
Hex-Head Ignitor Screws
Burner Ignitor
Connectors
To Next Page
