Whirlpool GI5FVAXVB02 - Freezer Liner Components

FREEZER LINER PARTS
12
For Models: GI5FVAXVB02
(Black)
W10288065
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Seviceable Part)
3 12002497 Gear (Left)
5
12812903WD Shaft, Rack
6 12570701 Socket, Light
7 12002497 Gear, (Right)
8 12990521 Screw, Bracket
9
W10194422 Bulb, Light
10
12476401SP Housing, Light
11 12935801 Cover, Evap
12 12990511 Screw
13 Bracket, Door
Slide
W10122147 Left
W10122148 Right
14
13027902SP Module, Freezer
Light
15 12956601 Clip, Fan Motor
16
12466111SP Switch, Rocker
17 12990504 Screw, Fan Shroud
To Basket
19
W10120018 Slide, Drawer (2)
20 A3189397 Gasket, Foam
21 Adapter
W10159938 Left
W10159939 Right
22 12959901 Grille, Air
23 12951401 Shroud, Evap Fan
24 12986101 Blade, Fan
(Evaporator)
25 12951101 Grommet, Fan
Motor (2)
26
W10162809 Motor, Evaporator
Fan
27 D7753903 Funnel, Drain
28 M0500703 Seal, O Ring
29 B8381501 Gasket,
Drain Tube
30 12002355 Thermistor Kit
31 12815301 Cover, Thermistor
32 12990501 Screw, Adapter
