CABINET PARTS
2
For Models: GI5FVAXVB02
(Black)
W10288065
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10238848
Tech Sheet
12828185SP
Use & Care Guide
W10202396
Guide, Energy
2 12961401 Tube W/Waterline,
Fill−IM
3 12698403 Block, Pivot
4 B5759655 Gasket, MC Back
5 Cover, Top Hinge
(Right)
12962302B
Black
6 Cover, Fill Tube
12981401B
Black
7 12961602 Cover, Control Box
8 M0108105 Clamp, Tube
9 12992602 Screw, Hinge Cover
10
12963205ED
Hinge, Top Right
11 12992201 Screw, Center
Hinge
12 12990511 Screw (3)
13 Cover, Top Hinge
(Left)
12962301B
Black
14 12992403 Screw, Top Hinge
15 Hinge, Center (RT)
13000008ED
Black
16 12957601 Box, HV Control
17 Cover, Corner (2)
12587703B
Black
18
12963204ED
Hinge, Top Left
19
12906303WD
Foot, Cabinet
20 12991302 Screw (8)
21 Shim, Top Hinge
12999501 Left
12999502 Right
22 Grille, Toe
12880103B
Black
23 12957701 Lid, HV Control
24 Hinge, Center (LT)
13000007ED
Black
25 12990702 Screw, Cover
26 Cabinet (Not A
Servicable Part)
27 12580304 Roller Assembly
28 12990302 Screw, Block
29 12957801 Gasket, HV Control
30
W10211858
Cover, MC Back
31
W10210988
Tube, Drain
33 12820505 Fiber, Acoustic
34 10354002 Brake, Foot
35
W10213583
Board, HV Control
To Next Page
