Whirlpool GI5FVAXVB02 - Dispenser Front Parts

DISPENSER FRONT PARTS
15
For Models: GI5FVAXVB02
(Black)
W10288065
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 Housing, Dispenser
(Not Serviced)
2 Dispenser Keyboard
W10164139 Black
3
W10162500 Board, L.V.
4 Sump, Dispenser
W10168726 Black
5 Chute, Ext/Yoke
(Includes Switch)
13005704B Black
6 12990513 Screw
7 12958301 Ring, Target
8 Facade, Dispenser
W10163996 Black
9 M0108106 Clamp, Tube
11 Yoke/Pad Assembly
W10168729 Black
12 12565502 Spring
