Whirlpool GI5FVAXVB02 - Freezer Door Assemblies; Freezer Door Components

FREEZER DOOR PARTS
16
For Models: GI5FVAXVB02
(Black)
W10288065
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 Freezer Door
12977834BQ Black
2 Handle, Door
W10223023 Black
3 Gasket, Door
W10164044 Black
4
W10150039 Basket, Lower
5
W10146439 Divider, Upper
Basket
6
W10146448 Basket, Upper
7
W10146440 Divider, Lower
Basket
8 13025202 Tray, Lower
Basket
9 Cradle, Basket
12812304 Right
12812303 Left
10 Gear Spur
W10158749 Right
W10146446 Left
11 Gear Mount
W10233899 Right
W10233898 Left
12 Rack
W10216620 Right
W10216619 Left
13 12992902 Screw, Handle
(Shoulder)
