Whirlpool GI5FVAXVB02 - Main Unit Parts List

UNIT PARTS
18
For Models: GI5FVAXVB02
(Black)
W10288065
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 12992301 Screw
2 12825803 Blade, Fan
3
W10210985 Basepan
4 12990511 Screw
5 2264017 Capacitor
6
W10217747 Tube, Discharge
7
W10119239 Harness, Evap.
Heater
8
W10215085 Pan, Drain
9
W10216919 Screw, Shoulder
10 12729123 Heater, Defrost
11
W10204187 Strap, Bale
12
W10197428 Start Device
13
W10137529 Grommet, Cond (4)
14
12639311SP Thermostat,
Defrost
15 12477102 Roller (2)
16 12992101 Screw
17
10835903SP Grommet (4)
18
W10135026 Condenser
19 10547003 Clip, Drier
20
12225403WD Tray, Drip
21 12990701 Screw
22 12959803 Evaporator
23 Dam
12963102SP Right Side
12963002SP Left Side
24 12825101 Motor, Fan
25 10428101 Clip, Heater
26
W10234027 Harness, Unit
with Power Cord
27
W10143759 Drier
28
W10134623 Compressor
(Includes items
11,12,17,27)
29 10623002 Clip, Evaporator
30 12477202 Axle, Roller (2)
31
W10189184 Shroud
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
5.25 Ozs.
(R−134A)
