Whirlpool GI5FVAXVB02 - Motor and Ice Container Lists

MOTOR AND ICE CONTAINER PARTS
8
For Models: GI5FVAXVB02
(Black)
W10288065
Illus. Part
No. No. DESCRIPTION
1 13012606 Ice Bin Assembly
(Includes Auger)
2
W10121282 Inlet, Blower
3
W10121281 Scroll, Blower
4
W10162697 Motor, Fan
5
W10123444 Wheel, Blower
6
12956603SP Clip, Fan Motor
7
W10151687 Grommet, Fan Motor
8
12958408SP Divider, Ice Box
9
12920001SP Gasket, Damper
10 12955405 Motor, Auger
11
W10127427 Damper, Control
12
13028201SP Solenoid
13
W10118612 Liner, Divider
14 12990511 Screw (3)
15
12958602SP Bracket, Solenoid
16
420107A700 Washer
17
63052A001 Yoke, Ice
Dispenser
18
12958502SP Yoke, Solenoid
19
12942401SP Spring, Solenoid
20
W10142628 Foil, Ice Box
