Whirlpool GSF26C5EXW - Accessing New in Door Ice Maker

4-13
Freezer Components (continued)
5. Remove the ice maker wire harness
cover and disconnect the harness.
6. Disconnect the wire harness to the emit-
ter and receiver boards.
7. Remove 2 - 1/4” screws under the ice
maker.
8. Slide out the ice maker to remove.
9. Remove 3 - ¼” screws to remove hous-
ing from the ice maker mold.
Accessing New In Door Ice Maker
5
6
8
7
