4-18
Freezer Components (continued)
Disassembling the ice maker (continued)
3. Separate the module from the head.
4. Remove two screws on the bottom of the
ice maker head and separate the head
from the mold. The thermostat can be
removed at this point.
5. When replacing the thermostat apply a
coating of Alumilastic to the mold.
This will provide a thermal bond between
the mold and thermostat.
To Next Page
