Whirlpool HB10813 - Remote Control Installation Guide

- 9 -
澬Installation of the Remote Control澭
1. Take out the remote control f
rom the holder.
2.
Install the remote control to suitable place
. Check the main body can receive signal from
the remote control installation location or take out the remote control to check the
receiver sensitivity. The installation location cannot be toward the direct spraying area
of the shower.
3.
Fix the remote con
trol holder to the designed place and make marks according to the
arrows.
4.
Dig hole
s according to the mark, fill the holes with 2 plastic plugs, and fix the holder with
screws.
5.
Install two R03 (AAA) batteries to the remote control:
A) Rotate the knob clockwise to the position ͺ
B) Open the battery coverͺ
C) Install two R03 (AAA) batteries to the remote controlͺ
(pay attention to the directions of positive and negative electrode)
D)
Replace the batt
ery coverͺ
E) Rotate the knob anti-clockwise to the position ͺ
6. Place the remote control back to the holder.
