4-8
1. Unplug washer or disconnect power.
2. Turn off the water supply to the washer.
3. Remove the top cover from the washer
(see page 4-2 for the procedure).
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
WARNING
REMOVING A WATER INLET VALVE
4. Disconnect the wire connectors from the
water inlet valve you are servicing.
5. Remove the two T-20 Torx screws from
the water inlet valve and remove the valve
from the rear of the unit.
Water Inlet Valves
Hot Water Inlet Valve
Red Wires
Cold Water Inlet Valve
2 Red
Black
Water Inlet Valve T-20 Torx Screws
