Whirlpool LSA 1100 - Sequence Chart; Program Timing Breakdown

SERVICE MANUAL
Page | 24
LSA1100
-
AGITATOR MODEL.
TIMING CHART
Program
Water level
Load sensing
& Fill duration
(In minutes)
Wash duration
(including inbuilt
soak) -In minutes
Rinse duration
(In minutes)
Spin duration
(In minutes)
Total cycle time
(In minutes)
Total cycle time
With Super Soak
(In minutes)
Daily wash
Low Water Level
1 17 7 6 31 45
Medium Water
level 1 21 8 6 36 52
High Water level
1 25 8.5 6 40.5 58.5
Quick Wash
Low Water Level
NA 5 6.5 4.5 16 SS not applicable
Medium Water
level NA 5 6.5 4.5 16 SS not applicable
High Water level
NA 5 6.5 4.5 16 SS not applicable
Delicates
Medium Water
level NA 14 5.5 4 23.5 33.5
High Water level
NA 18 6.5 4 28.5 42.5
Easy Iron
Medium Water
level NA 17 6 4 27 39
High Water level
NA 22 7 4 33 48
Wool
Medium Water
level NA NA NA NA NA SS not applicable
High Water level
NA 23 7 4 34 SS not applicable
Bedlinen
Low Water Level
1 23 15 6.5 44.5 58.5
Medium Water
level 1 31 16 6.5 53.5 70.5
High Water level
1 36 17 6.5 59.5 79.5
Whites
Low Water Level
NA 70 8 4.5 82.5 SS not applicable
Medium Water
level NA NA NA NA NA SS not applicable
High Water level
NA NA NA NA NA SS not applicable
Colors
Low Water Level
NA NA NA NA NA NA
Medium Water
level NA 13 6 4 23 33
High Water level
NA 18 7 4 29 41
Delicates Low Low
NA NA NA NA NA NA
Easy Iron Low Low
NA NA NA NA NA NA
Rinse & Spin
Low Water Level
NA
–
7 6 13 SS not applicable
Medium Water
level NA
–
7.5 6 13.5 SS not applicable
High Water level
NA
–
8 6 14 SS not applicable
Spin – – – –
6 6 SS not applicable
Note: a) The total cycle time depends on the water pressure and fill time, the table is based on the normal water pressure (fill time is not included because it
based on the pressure it will change fill time accordingly).
b) Every extra rinse will add approximately 17 minutes.
c) Modifying the program with extra features will increase cycle time accordingly.
SEQUENCE CHART
