Whirlpool M-17 - Component Locations

For Service Technician Use Only
COMPONENT TESTING (Cont.)
Whirlpool
®
and KitchenAid
®
Filtration and Maytag
®
24" Microltration Dishwashers
n
3-25

A
B
C
D
E
F
G
A. Water Feed Tube
B. Water Inlet Opening
C. Coarse Filter
D. HeangElement
E. DetergentDispenser
F. AcveVents(OnSomeModels)
G. LowerSprayArm
