MSEX0105i – Electronic No Frost Refrigerator Bottom Mount/ Dual Fan - Maestro High 24
- Disassembly
For accessing the Freezer internal components remove the sensor Support, the Sensor itself (from the
Support) and then disconnect the FC Fan Motor Connector. Finally, just loosen the 4 screws at the sides
of the Cover and pull it out.
In order to disassembly the Fan Motor, just remove the 4 screws that are attaching its support. When
reassembling take care with the wires position and sealing tapes.
Remove
Remove
Remove
Remove
