LOWER OVEN DOOR PARTS
5
8185829
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
For Models:RBD245PDB12, RBD245PDQ12, RBD245PDT12,RBD245PDS12
(Black) (Designer White) (Biscuit) (Stainless Steel)
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1 4455616 Liner, Door
3 4449247 Glass, Inner
5 8300776 Retainer, Glass
4449809 Screw
6 Hinge, Door
8300780 Right Side
8300781 Left Side
4449743 Screw
12 Door Glass, Assy
8300917 Black Model
8300916 White Model
8300913 Biscuit Model
8300993 S.Steel Model
13 Door Handle
4448402 Black Model
4448403 White Model
8300512 Biscuit Model
14 4450813 Bracket, Handle
4451040 Screw
20 4450863 Retainer, Glass
23 Retainer, Clip
4450863 Black Model
4450864 White Model
To Next Page
