54
beverage center for the first time, remove all of the packing
beverage center should be located on a firm, flat surface that is strong enough
beverage center
4
4
beverage center legs must be adjusted during installation in order to function
left
right
BEVERAGE STORAGE
1. The maximum capacity of WHB45S is 108 cans (335ml) when laid vertically.
2. To achieve the maximum capacity, place 30 cans in the top 3 racks as shown
below in Figure A, six cans per row, five cans per column.
3. Next, place 18 cans in the bottom rack as shown below in Figure B, three cans
per row and six cans per column.
4. Store beverages in sealed cans only.
B
5. Do not Put the units in the place where it is subjected to a strong light.
6. Do not Put the units in the palce where the ambiebt temperature is higher than 90 degree.
7. Before loading cans,suggest to cool the unit to the setting temperature,and
loading so many cans one time.
not
