WINE STORAGE
1. The maximum capacity of is 40 wine bottles (750ml).WHW45S
2. To achieve the maximum capacity, place 6 bottles in the top 6 racks as shown
below in Figure A. ’’Please note that top rack only holds 4 bottles. ’’
3. Next, place 3 bottles sideways in the bottom 2 racks as shown below in Figure B.
4. Store wine in sealed bottles only.
Please see the above image which shows you five popular dimensions of wine
bottles.
The maximum capacity is based on “Typical Bordeaux” bottle dimension.
If storing larger bottles, the capacity will be reduced.
Bottle Sizes and Storage Capacity
LARGE
CALIFORNIA
RED
TYPICAL
PINOT
NOIR
TYPICAL
BORDEAUX
TYPICAL
RIESLING
CHAMPAGNE/
SPARKLING
3"
3- 1/8"
2- 3/4"
2- 3/4"
3- 3/4"
9- 1/2"
7- 1/2"
8- 1/2"
6- 1/2"
7"
12 -1/4 "
13 "
11 -3/4 "
11 -7/8 "
12 -7/8 "
