Whirlpool WS68G8CHW/E - Page 46

*with dry gas 15°C 1013 mbar
** Propane P.C.S=50,37 MJ/Kg
*** Butane P.C.S=49,47MJ/kg
Natural G20 P.C.S=37,78Mj/m³
Table of burner and nozzle specifications
Liquid Gas Natural Gas
Thermal Power
kW (p.c.s*)
By-Pass
1/100
(mm)
Nozzle
1/100
(mm)
Flow
g/h
Nozzle
1/100
(mm)
Flow
g/h
Burner Diameter (mm) Nominal Reduced *** **
TC
130 3.30 1.50 61 2x65 240 236 2x99 314
Semi Rapid
(Medium) (S)
75 2.00 0.40 30 69 145 143 104 190
Auxiliary
(Small) (A)
55 1.00 0.40 30 50 73 71 78 95
Supply
Pressures
Nominal (mbar)
Minimum (mbar)
Maximum
28-30
20
35
37
25
45
20
17
25
46
