Functional characteristics
NTC senor in the refrigerator compartment
ON CONDITIONS:
When the fridge NTC sensor temperature is equal or higher than the ON value
corresponding to the user setting the following operation must be performed:
- The damper must be driven in OPEN position
- The evaporator fan must be switched ON
One NTC sensor is provided in the refrigerator compartment to control the temperature by means of the
evaporator fan and the damper. The Refrigerator Control Table defines the ON/OFF temperature values for
every possible user setting.
OFF CONDITIONS:
When the fridge NTC sensor temperature is equal or lower than the OFF value
corresponding to the user setting the following operation must be performed:
- The damper must be driven in CLOSE position
- The evaporator fan must be switched OFF unless the compressor is running
in order to cool the freezer section.
Refrigerator Display Damper ON ( C) Damper OFF ( C)
6 7,5 5,5
5 6,5 4,5
4 5 3,5
3 4 2,5
2 3 1,5
Super Cooling 3 1,5
