Whirlpool WSF7256 IX - NTC sensor in the freezer compartment

Functional characteristics
NTC senor in the freezer compartment
ON CONDITIONS
When the freezer NTC sensor temperature is equal or higher than the ON value
corresponding to the user setting the following operation must be performed:
- The compressor must be switched ON
- The evaporator fan must be switched ON
OFF CONDITIONS
When the freezer NTC sensor temperature is equal or lower than the OFF value
corresponding to the user setting the following operation must be performed:
- The compressor must be switched OFF
- The evaporator fan must be switched OFF unless the
refrigerator compartment requires to be cooled.
One NTC sensor is provided in the freezer compartment to control the temperature by means of the compressor
and the evaporator fan.
The Freezer Control Table defines the ON/OFF temperature values for every possible user setting.
See on the next slide for the different version.
