Whirlpool WSFC 3M17 X - Options and Functions; MultiZone Function; Sani Rinse Function; Tablet Function

36
Quick GuideEN
KEYLOCK - A long press (for 3 seconds) of MULTIZONE button, will
activate the KEYLOCK function. To deactivate the KEYLOCK, long press again.
DELAY -The start of the program may be delayed for a period of time
between 0:30 and 24 hours.
The DELAY function cannot be set once a wash cycle has been started.
TABLET (Tab)- If you use powder or liquid detergent, this option
should be o.
OPTIONS AND FUNCTIONS
OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected
program (see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.
MULTIZONE - If there are not many dishes to be washed, a half load-
ing may be used in order to save water, electricity and detergent.
Bydefault the appliance washes dishes in all racks.
SANI RINSE - This option can be used to sanitize washed dishes.
It will increase nal rinse temperature and add antibacterial wash to the
selected program. WARNING: the crockery and plates could be extremely
hot at the end of the cycle.
Please scan the QR code on your product in order to have more detailed information.
UPPER RACK
(loading example for the
upper rack)
Load delicate and light
dishes: glasses, cups, saucers,
low salad bowls.
LOWER RACK
(loading example for the
lower rack)
For pots, lids, plates, salad
bowls, cutlery etc.. Large
plates and lids should ide-
ally be placed at the sides
to avoid interferences with
the spray arm.
FOLDABLE
FLAPS
WITH AD-
JUSTABLE
POSITION
CUTLERY BASKET
The basket is equipped with top grilles for improved cutlery arrangement.
The cutlery basket should be positioned only at the front of the lower rack.
Knives and other utensils with sharp edges must be placed in the
cutlery basket with the points facing downwards or they must be po-
sitioned horizontally in the tip-up compartments on the upper rack.
CLEANING AND MAINTENANCE
More information in the Daily Reference Guide on website.
LOADING THE RACKS
CAPACITY: 10 standard place-settings
In case your dishwasher doesn’t work properly, check if the problem can be solved by going through the following list. For other errors or issues
please contact authorized After-sales Service which contact details can be found in the warranty booklet. Spare parts will be available for a period
of either up to 7 or up to 10 years, according to the specic Regulation requirements.
TROUBLESHOOTING
Policies, standard documentation, ordering of spare parts and additional product information can be found by:
• Using QR code on your product.
• Visiting our website docs.whirlpool.eu and parts-selfservice.whirlpool.com
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When contacting our After-
sales Service, please state the codes provided on your product‘s identication plate.
The model information can be retrieved using the QR-Code reported in the energy label. The label also includes the model
identier that can be used to consult the portal of the registry at https://eprel.ec.europa.eu.
IEC 436
:
CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS
1
A
2
A
B
3
C
4
In case you nd foreign objects (such as broken glass, porcelain, bones, fruit seeds
etc.) please remove them carefully.
NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).
To remove the upper spray arm,
turn the plastic locking ring in a
clockwise direction.
The lower spray arm may
be removed by pulling it
upwards.
Please scan the QR code on your product in order to have more detailed information.
PROBLEMS POSSIBLE CAUSES SOLUTIONS
The dishwasher does not
ll the water. Display shows:
and F6, both On/O
and START/Pause LEDs are
blinking rapidly.
No water in the water supply or the tap is closed. Make sure there is water in the water supply or the tap running.
The inlet hose is bent.
Make sure the inlet hose is not bent (see INSTALLATION) reprogram the dishwasher
and reboot.
The sieve in the water inlet hose is clogged; it is
necessary to clean it.
After having carried out the verication and cleaning, turn o and turn on the dish-
washer and restart a new program.
Dishwasher nishes the cycle
prematurely.
Display shows: F15 and both
On/O and START/Pause
LEDs are blinking rapidly.
Drain hose positioned too low or siphoning into
home sewage system.
Check if end of drain hose is placed at correct height (see INSTALLATION).Check for
siphoning into home sewage system, install air admittance valve if necessary.
Air in water supply. Check water supply for leaks or other issues letting air inside.
