5
CIRCUIT DIAGRAM
WVIID1058BKG
WVWD1050&950&850BKG
THOUBLESHOOTING
a. Power Source
Yes
No
COLOR SYMBOL
Gr
Bl
G
B
LB
Br
O
P
R
W
Y
V
GRAY
BLUE
GREEN
BLACK
LIGHT BLUE
BROWN
ORANGE
PINK
RED
WHITE
YELLOW
VIOLET
TROUBLE
CAUSES
REMEDY
Any indications
and beep do not
work when
power switch is
on and the start
button is pressed
Deterioration of fuse.
Motor is defective.
Capacitor is defective.
Replace.
Replace.
Replace.
Poor connect of
connectors
Control circuit board is
defective
Repair or replace.
Replace.
