39
D Remove the five screws on the front
of the drying duct and remove the
harness.
E Remove the eight fastening
screws on the front of the drying duct
to remove the drying duct.
F Remove the 4 screws from the fan
motor on the front of the drying
duct. Remove the screw on the
opposite side with a special tool.
Remove the fan motor.
G Remove the seal ring. Take down
the screws to remove the heating tube
and the insulation board.
