Safety • Assembly • Operation • Tips & Techniques • Maintenance • Troubleshooting • Parts Lists • Warranty
Warning: This unit is equipped with an internal combustion engine and should not be used on or near any unimproved forest-covered, brush-
covered or grass-covered land unless the engine’s exhaust system is equipped with a spark arrester meeting applicable local or state laws (if any).
If a spark arrester is used, it should be maintained in effective working order by the operator. In the State of California the above is required by law
(Section 4442 of the California Public Resources Code). Other states may have similar laws. Federal laws apply on federal lands. A spark arrester
for the muffler is available through your nearest engine authorized service dealer or contact the service department, P.O. Box 361131 Cleveland,
Ohio 44136-0019.
MTD LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
PRINTED IN U.S.A
READ SAFETY RULES AND INSTRUCTIONS CAREFULLY BEFORE OPERATION
IMPORTANT
OPERATOR’S MANUAL
20-inch Mulching Push Lawn Mower — Model 105
3/1/2006
FORM NO. 769-01447B

Table of Contents

Questions and Answers

  • J
    Jacqueline GonzalezAug 20, 2025
    Why won't my White Outdoor 105 start?
    • J
      Julie GriffinAug 20, 2025
      Your White Outdoor Lawn Mower might not start due to several reasons: the blade control might be disengaged (engage it), the spark plug wire could be disconnected (connect it), the fuel tank might be empty or contain stale fuel (fill it with fresh gasoline), the engine may not be choked (choke it as instructed), the spark plug could be faulty (clean, adjust the gap, or replace it), the fuel line might be blocked (clean it), or the engine could be flooded (wait a few minutes before restarting, without priming).
  • S
    Sean LoganAug 22, 2025
    Why is my White Outdoor Lawn Mower engine running erratically?
    • K
      Kevin DavisAug 22, 2025
      An erratic engine in your White Outdoor Lawn Mower could be caused by a loose spark plug wire (connect and tighten it), a blocked fuel line or stale fuel (clean the fuel line and refill with fresh gasoline), a plugged vent in the gas cap (clear the vent), or water/dirt in the fuel system (drain the tank and refill with fresh fuel). For a dirty air cleaner or a carburetor out of adjustment, please refer to the engine manual.
  • M
    Megan AdamsAug 25, 2025
    What to do if my White Outdoor Lawn Mower engine overheats?
    • B
      Bruce LeeAug 25, 2025
      If your White Outdoor Lawn Mower engine overheats, check the engine oil level and fill the crankcase with the proper oil if it's low. Also, ensure that the air flow is not restricted by removing the blower housing and cleaning it. For carburetor adjustments, please refer to the engine manual.
  • C
    christopherbyrdAug 26, 2025
    How to fix an uneven cut with my White Outdoor 105 Lawn Mower?
    • J
      Jennifer PayneAug 26, 2025
      An uneven cut with your White Outdoor Lawn Mower can be due to wheels not positioned correctly (place all four wheels in the same height position) or a dull blade (sharpen or replace the blade).
  • L
    Linda HarringtonAug 28, 2025
    Why won't my White Outdoor Lawn Mower mulch grass properly?
    • S
      Shaun WrightAug 28, 2025
      If your White Outdoor Lawn Mower isn't mulching grass properly, it could be due to wet grass (do not mow when grass is wet; wait until it's dry), excessively high grass (mow once at a high cutting height, then again at the desired height, or make a narrower cutting path), or a dull blade (sharpen or replace the blade).
  • J
    Jesse AllenAug 29, 2025
    What causes my White Outdoor Lawn Mower to idle poorly?
    • K
      Kayla PopeAug 29, 2025
      Poor idling in your White Outdoor Lawn Mower can result from a spark plug that is fouled, faulty, or has a gap that is too wide (reset the gap to .030-inch or replace the spark plug). For carburetor adjustments or a dirty air cleaner, please refer to the engine manual.
  • R
    richard95Aug 31, 2025
    Why does my White Outdoor 105 skip at high speed?
    • S
      Shelley RoweAug 31, 2025
      Occasional skipping (hesitation) at high speed in your White Outdoor Lawn Mower may be due to a spark plug gap that is too close (adjust the gap to .030-inch). For carburetor idle mixture adjustments, please refer to the engine manual.
  • G
    Gary AdamsSep 2, 2025
    Why White Outdoor 105 engine fails to start?
    • D
      derekhillSep 2, 2025
      Your White Outdoor Lawn Mower engine might fail to start due to several reasons: the blade control may be disengaged (engage it); the spark plug wire may be disconnected (connect it); the fuel tank may be empty or contain stale fuel (fill it with clean, fresh gasoline); the engine may not be primed (prime it as instructed); the spark plug may be faulty (clean, adjust the gap, or replace it); the fuel line may be blocked (clean it); or the engine may be flooded (wait a few minutes to restart, but do not prime).
  • J
    Jesse AyalaSep 4, 2025
    Why does my White Outdoor Lawn Mower engine run erratically?
    • M
      Mark SanchezSep 4, 2025
      An erratic running engine in your White Outdoor Lawn Mower could be caused by a loose spark plug wire (connect and tighten it), a blocked fuel line or stale fuel (clean the fuel line and fill the tank with fresh gasoline), a plugged vent in the gas cap (clear the vent), or water or dirt in the fuel system (drain the fuel tank and refill with fresh fuel). For a dirty air cleaner or carburetor adjustment issues, please refer to the engine manual.
  • A
    amanda22Sep 6, 2025
    What to do if White Outdoor 105 Lawn Mower has excessive vibration?
    • K
      Kenneth SanchezSep 6, 2025
      Excessive vibration in your White Outdoor Lawn Mower can be attributed to a loose or unbalanced cutting blade (tighten the blade and adapter, and balance the blade). If the cutting blade is bent, consult an authorized service dealer.

Summary

Slope Gauge

Slope Safety Warning

Warning about operating mower on inclines exceeding 15 degrees to prevent overturn or injury.

Safe Operation Practices

General Safety Warnings

Key warnings about machine capabilities, operator responsibility, and potential for serious injury or death.

Child Safety Precautions

Ensures children are kept away from the mower and never operate it until age 14 and supervised.

General Operation Guidelines

Slope Operation Guidelines

Setup and Adjustment

Handle Setup

Wheel Height Adjustment

Operating Your Lawn Mower

Gas and Oil Fill-Up

Essential steps for safely adding fuel and oil to the engine before operation.

Starting Engine

Detailed steps and safety precautions for starting the lawn mower engine.

Stopping Engine

Procedure for safely shutting down the engine and blade.

Using Your Lawn Mower

Maintaining Your Lawn Mower

Lubrication

Blade Care

Instructions for inspecting, sharpening, balancing, and reinstalling the mower blade.

Troubleshooting

Engine Problems

Mowing Performance Issues

Safety Labels

DANGER and WARNING Labels

Explanation of critical safety labels and warnings to be adhered to for safe operation.

White Outdoor 105 Specifications
