IMPORTANT: Read safety rules and instructions carefully before operating equipment.
WHITE OUTDOOR PRODUCTS COMPANY P.O. BOX 361131 CLEVELAND, OHIO 44136-9722
Rear Tine
Tiller
RB650
21A-458B190
PRINTED IN U.S.A.
Warning:
This unit is equipped with an internal combustion engine and should not be used on or near any unimproved forest-
covered, brush-covered or grass-covered land unless the engine’s exhaust system is equipped with a spark arrester meeting
applicable local or state laws (if any). If a spark arrester is used, it should be maintained in effective working order by the operator.
In the State of California the above is required by law (Section 4442 of the California Public Resources Code). Other states may have
similar laws. Federal laws apply on federal lands. A spark arrester for the muffler is available through your nearest engine authorized
service dealer or contact the service department, P.O. Box 361131 Cleveland, Ohio 44136-9722.
Operator’s Manual
FORM NO.
770-10193C.fm
(12/99)

Questions and Answers

  • S
    Shannon TaylorJul 30, 2025
    Why won't my White Outdoor Tiller engine start?
    • K
      Kevin BuchananJul 30, 2025
      The engine may fail to start due to several reasons: * The fuel tank might be empty or the fuel is stale. In this case, fill the tank with clean, fresh gasoline. Note that fuel will not last over thirty days unless a fuel stabilizer is used. * The throttle control lever might not be in the correct starting position. If equipped, move the throttle lever to the start position. * The fuel line could be blocked. Clean the fuel line. Refer to the engine manual packed with your unit. * The choke might not be in the ON position. Move the switch to the ON position. * The spark plug wire might be disconnected. Connect the wire to the spark plug. * The spark plug might be faulty. Refer to the engine manual packed with your unit.
  • A
    abigail85Aug 4, 2025
    Why does my White Outdoor RB650 Tiller engine run erratically?
    • S
      Shane AustinAug 4, 2025
      An engine that runs erratically on a White Outdoor Tiller can be caused by: * The unit running on CHOKE. To resolve this, move the choke lever to the OFF position. * A loose spark plug wire. Connect and tighten the spark plug wire. * A blocked fuel line or stale fuel. Clean the fuel line and fill the tank with clean, fresh gasoline. Remember, fuel will not last over thirty days unless a fuel stabilizer is used. * A plugged vent in the gas cap. Clear the vent.
  • A
    Aaron PonceAug 8, 2025
    Why does my White Outdoor Tiller engine over-heat?
    • Y
      ymcbrideAug 8, 2025
      Your White Outdoor Tiller engine may overheat due to: * Low engine oil level. Fill the crankcase with the proper oil, referring to the engine manual packed with your unit. * Carburetor not adjusted properly. Adjust the carburetor as instructed in the separate engine manual.
  • N
    Nathan WashingtonAug 14, 2025
    What to do if the tines do not engage on my White Outdoor Tiller?
    • D
      Destiny BrewerAug 14, 2025
      If the tines on your White Outdoor Tiller do not engage, it could be due to: * A foreign object lodged in the tines. Dislodge the foreign object. * Missing tine clevis pins. Replace the tine clevis pins. * A worn and/or stretched belt. Replace the belt.
  • T
    Tonya RubioAug 18, 2025
    What to do if the wheels do not engage on my White Outdoor RB650?
    • S
      Sheila AlvaradoAug 18, 2025
      If the wheels on your White Outdoor Tiller do not engage, it may be because: * A clevis pin is missing. Replace the clevis pin. * The belt is worn and/or stretched. Replace the belt.
  • J
    jessehollandAug 25, 2025
    Why do the tines skip over ground on my White Outdoor Tiller?
    • B
      Barbara BishopAug 25, 2025
      Tines on the White Outdoor Tiller skip over the ground because forward rotation should only be used on soil that has already been tilled, not on virgin soil.

Summary

Important Safe Operation Practices

General Operation Guidelines

Outlines general rules and precautions for operating the tiller safely and effectively.

Assembling Your Tiller

Attaching Depth Stake Assembly

Instructions for mounting the depth stake assembly to the tiller.

Attaching the Handle Assembly

Steps to attach the tiller's handle assembly securely.

Attaching the Clutch Cable

Procedure for connecting the clutch cable to the tiller handle.

Attaching the Control Rod

Instructions for installing the tiller's control rod.

Know Your Tiller

Operating Your Tiller

Engine Starting Procedure

Step-by-step guide for starting the tiller's engine.

Tiller Operation Guide

Instructions for operating the tiller in various modes and conditions.

Making Adjustments

Service

Maintaining Your Tiller

Trouble Shooting Guide

White Outdoor RB650 Specifications

General IconGeneral
EngineBriggs & Stratton
Engine Size6.5 HP
Engine Displacement190 cc
Tine DirectionForward rotating
Engine Type4-cycle OHV
